Image is for reference only , See Product Specifications
22-17-3102
| Manufacturers: | Molex |
|---|---|
| Product Category: | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Data Sheet: | 22-17-3102 |
| Description: | CONN RCPT 10POS 0.1 GOLD PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Style | Board to Board or Cable |
| Series | KK 4455 |
| Features | Board Hooks |
| Packaging | Tray |
| Part Status | Active |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact Type | Non-Gendered |
| Contact Shape | Square |
| Mounting Type | Through Hole |
| Connector Type | Receptacle, Bottom Entry |
| Fastening Type | Push-Pull |
| Number of Rows | 1 |
| Pitch - Mating | 0.100" (2.54mm) |
| Voltage Rating | 250VAC |
| Contact Material | Brass |
| Insulation Color | White |
| Insulation Height | 0.311" (7.90mm) |
| Ingress Protection | - |
| Insulation Material | Polyamide (PA), Nylon |
| Number of Positions | 10 |
| Row Spacing - Mating | - |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.132" (3.35mm) |
| Current Rating (Amps) | 2.5A |
| Operating Temperature | -40°C ~ 80°C |
| Mated Stacking Heights | - |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 50.0µin (1.27µm) |
| Contact Finish Thickness - Mating | 15.0µin (0.38µm) |
In Stock 1 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.36 | $1.33 | $1.31 |
