| Manufacturer |
Harwin Inc. |
| Product Category |
Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Style |
Board to Board or Cable |
| Series |
Datamate J-Tek |
| Features |
Jackscrews, Mating Flange, Mounting Flange, Polarizing Key |
| Packaging |
Tube |
| Part Status |
Active |
| Termination |
Solder |
| Applications |
Automotive, General Purpose, Military |
| Contact Type |
Female Socket |
| Contact Shape |
Circular |
| Mounting Type |
Through Hole |
| Connector Type |
Receptacle |
| Fastening Type |
Screw Lock |
| Number of Rows |
2 |
| Pitch - Mating |
0.079" (2.00mm) |
| Voltage Rating |
120V |
| Contact Material |
Beryllium Copper |
| Insulation Color |
Black |
| Insulation Height |
0.205" (5.20mm) |
| Ingress Protection |
- |
| Insulation Material |
Polyphenylene Sulfide (PPS), Glass Filled |
| Number of Positions |
26 |
| Row Spacing - Mating |
0.079" (2.00mm) |
| Contact Finish - Post |
Tin |
| Contact Length - Post |
0.118" (3.00mm) |
| Current Rating (Amps) |
- |
| Operating Temperature |
-55°C ~ 125°C |
| Mated Stacking Heights |
7.3mm, 7.55mm |
| Contact Finish - Mating |
Gold |
| Number of Positions Loaded |
All |
| Material Flammability Rating |
UL94 V-0 |
| Contact Finish Thickness - Post |
137.8µin (3.50µm) |
| Contact Finish Thickness - Mating |
12.0µin (0.30µm) |
