Image is for reference only , See Product Specifications
JCA0612D01
| Manufacturers: | XP Power |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | JCA0612D01 |
| Description: | DC DC CONVERTER +/-5V 6W |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | XP Power |
| Product Category | DC DC Converters |
| Type | Isolated Module |
| Series | JCA (6W) |
| Features | OCP, OVP, SCP, UVLO |
| Packaging | Tube |
| Efficiency | 82% |
| Part Status | Active |
| Applications | ITE (Commercial) |
| Mounting Type | Through Hole |
| Power (Watts) | 6W |
| Package / Case | 24-DIP Module, 8 Leads |
| Size / Dimension | 1.00" L x 0.80" W x 0.39" H (25.4mm x 20.3mm x 10.0mm) |
| Number of Outputs | 2 |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | -5V |
| Voltage - Output 3 | - |
| Voltage - Isolation | 1.5kV |
| Operating Temperature | -40°C ~ 100°C |
| Voltage - Input (Max) | 18V |
| Voltage - Input (Min) | 9V |
| Current - Output (Max) | 500mA, 500mA |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $30.46 | $29.85 | $29.25 |
