329697
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | Terminals - Rectangular Connectors |
| Data Sheet: | 329697 |
| Description: | CONN TERM RECT 10-12 AWG #6 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | Terminals - Rectangular Connectors |
| Color | Yellow |
| Series | PIDG |
| Features | Serrated Termination |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 10-12 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 6 Stud |
| Tab Thickness | 0.040" (1.02mm) |
| Terminal Type | Standard |
| Contact Finish | Tin |
| Terminal Style | Single Stud Hole |
| Contact Material | Copper |
| Length - Overall | 1.085" (27.56mm) |
| Diameter - Ring ID | 0.145" (3.68mm) |
| Width - Outer Edges | 0.250" (6.35mm) |
| Diameter - Barrel ID | - |
| Diameter - Barrel OD | - |
In Stock 1719 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.85 | $0.83 | $0.82 |
