Image is for reference only , See Product Specifications
41330
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | Terminals - Ring Connectors |
| Data Sheet: | 41330 |
| Description: | CONN RING CIRC 14-18AWG #6 CRIMP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | Terminals - Ring Connectors |
| Color | - |
| Series | - |
| Features | - |
| Packaging | Cut Tape (CT) |
| Thickness | 0.020" (0.51mm) |
| Insulation | Non-Insulated |
| Wire Gauge | 14-18 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 6 Stud |
| Terminal Type | Circular |
| Contact Finish | Tin |
| Contact Material | Brass |
| Length - Overall | 0.640" (16.26mm) |
| Insulation Diameter | 0.120" ~ 0.170" (3.05mm ~ 4.32mm) |
| Width - Outer Edges | 0.296" (7.52mm) |
| Material - Insulation | - |
In Stock 24033 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.22 | $0.22 | $0.21 |
