Image is for reference only , See Product Specifications
SMB7H-J-P-H-RA-TH1
| Manufacturers: | Samtec, Inc. |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | SMB7H-J-P-H-RA-TH1 |
| Description: | CONN SMB JACK R/A 75 OHM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Samtec, Inc. |
| Product Category | Coaxial Connectors (RF) |
| Series | TRUE75™ SMB7H |
| Features | - |
| Includes | - |
| Impedance | 75Ohm |
| Packaging | Tray |
| Body Finish | Gold |
| Cable Group | - |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Gold |
| Mating Cycles | - |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Jack, Male Pin |
| Fastening Type | Snap-On |
| Insertion Loss | - |
| Voltage Rating | 335V |
| Connector Style | SMB |
| Frequency - Max | 4GHz |
| Number of Ports | 1 |
| Mounting Feature | - |
| Ingress Protection | - |
| Shield Termination | Solder |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -65°C ~ 165°C |
| Center Contact Plating | Gold |
| Center Contact Material | Brass |
In Stock 142 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $8.26 | $8.09 | $7.93 |
