| Manufacturer |
Amphenol RF Division |
| Product Category |
Coaxial Connectors (RF) |
| Series |
- |
| Features |
- |
| Includes |
6 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Gasket, 1 Lockwasher, 1 Nut |
| Impedance |
50Ohm |
| Packaging |
Bulk |
| Body Finish |
Nickel |
| Cable Group |
RG-178, 178A, 178B, 196, 196A, M17/93-RG178 |
| Part Status |
Active |
| Body Material |
Brass |
| Housing Color |
Silver |
| Mating Cycles |
500 |
| Mounting Type |
Panel Mount |
| Connector Type |
Jack, Female Socket |
| Fastening Type |
Bayonet Lock |
| Insertion Loss |
0.2dB |
| Voltage Rating |
500V |
| Connector Style |
BNC |
| Frequency - Max |
4GHz |
| Number of Ports |
1 |
| Mounting Feature |
Bulkhead - Front Side Nut |
| Ingress Protection |
- |
| Shield Termination |
Crimp |
| Contact Termination |
Crimp |
| Dielectric Material |
Polytetrafluoroethylene (PTFE) |
| Operating Temperature |
- |
| Center Contact Plating |
Gold |
| Center Contact Material |
Phosphor Bronze |
