Image is for reference only , See Product Specifications
JK0-0145NL
| Manufacturers: | Pulse Electronics Network |
|---|---|
| Product Category: | Modular Connectors - Jacks With Magnetics |
| Data Sheet: | JK0-0145NL |
| Description: | CONN MAGJACK 1PORT 1000 BASE-TX |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Pulse Electronics Network |
| Product Category | Modular Connectors - Jacks With Magnetics |
| Series | PULSEJACK™ JK0 |
| Features | Board Guide |
| LED Color | Green - Yellow |
| Packaging | Tray |
| Shielding | Shielded, EMI Finger |
| Orientation | 90° Angle (Right) |
| Part Status | Active |
| Termination | Solder |
| Applications | 10/100/1000 Base-TX, AutoMDIX |
| Mounting Type | Through Hole |
| Tab Direction | Up |
| Connector Type | RJ45 |
| Contact Finish | Gold |
| Number of Rows | 1 |
| Number of Ports | 1 |
| Shield Material | Brass |
| Contact Material | Phosphor Bronze |
| Height Above Board | 0.546" (13.87mm) |
| Dielectric Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
| Contact Finish Thickness | 15.0µin (0.38µm) |
| Number of Cores per Jack | 8 |
In Stock 405 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $11.44 | $11.21 | $10.99 |
