Image is for reference only , See Product Specifications
2301997-2
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | Modular Connectors - Jacks With Magnetics |
| Data Sheet: | 2301997-2 |
| Description: | CONN MAGJACK 2PORT 100 BASE-T |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | Modular Connectors - Jacks With Magnetics |
| Series | - |
| Features | Board Lock |
| LED Color | Does Not Contain LED |
| Packaging | Tray |
| Shielding | Shielded, EMI Finger |
| Orientation | 90° Angle (Right) |
| Part Status | Active |
| Termination | Solder |
| Applications | 10/100 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Tab Direction | Up and Down |
| Connector Type | RJ45 |
| Contact Finish | Gold |
| Number of Rows | 2 |
| Number of Ports | 2 |
| Shield Material | Brass |
| Contact Material | Copper Alloy |
| Height Above Board | 1.006" (25.55mm) |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Operating Temperature | -40°C ~ 85°C |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Number of Cores per Jack | 4 |
In Stock 2726 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $11.07 | $10.85 | $10.63 |
