Image is for reference only , See Product Specifications
3240166
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 3240166 |
| Description: | TERM BLOCK PLUG 8POS STR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Transparent |
| Pitch | - |
| Series | JBC |
| Features | - |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 20A |
| Voltage - UL | 600V |
| Current - IEC | 24A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 450V |
| Torque - Screw | - |
| Plug Wire Entry | 180° |
| Contact Material | - |
| Number of Levels | 1 |
| Insulation Height | 0.350" (8.89mm) |
| Termination Style | Screwless - Spring Cage, Tension Clamp |
| Wire Strip Length | 8mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | - |
| Number of Positions | 8 |
| Positions Per Level | 8 |
| Contact Mating Finish | - |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 16-20 AWG |
| Wire Gauge or Range - mm² | 0.5-2.5mm² |
| Material Flammability Rating | UL94 V-2 |
In Stock 86 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.61 | $0.60 | $0.59 |
