Image is for reference only , See Product Specifications
691386700002
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 691386700002 |
| Description: | TERM BLOCK HDR 2POS VERT 5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Header, Blade Pins |
| Color | Gray |
| Pitch | 0.197" (5.00mm) |
| Series | WR-TBL Series 386 |
| Features | - |
| Packaging | Tray |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 14A |
| Voltage - UL | 300V |
| Current - IEC | 16A |
| Mounting Type | Through Hole |
| Voltage - IEC | 250V |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.429" (10.90mm) |
| Termination Style | Solder |
| Wire Strip Length | - |
| Header Orientation | Vertical |
| Ingress Protection | - |
| Contact Tail Length | 0.161" (4.10mm) |
| Dielectric Material | Polycarbonate (PC) |
| Number of Positions | 2 |
| Positions Per Level | 2 |
| Contact Mating Finish | - |
| Operating Temperature | -30°C ~ 130°C |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 50 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.56 | $0.55 | $0.54 |
