3205048
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3205048 |
| Description: | CONN TERM BLK FEED THRU 16-24AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Gray |
| Series | CLIPLINE QTC |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 10A |
| Voltage - UL | 600V |
| Current - IEC | 17.5A |
| Voltage - IEC | 800V |
| Disconnect Type | - |
| Number of Levels | 1 |
| Stripping Length | - |
| Terminal - Width | 5.2mm |
| Termination Style | IDC |
| Number of Positions | 3 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 16-24 AWG |
| Wire Gauge or Range - mm² | 0.25-1.5mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 1444 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.03 | $2.97 | $2.91 |
