Image is for reference only , See Product Specifications
0701011
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 0701011 |
| Description: | CONN TERM BLK FEED THRU 6-20 AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Gray |
| Series | CLIPLINE URK |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Voltage - UL | - |
| Current - IEC | 70A |
| Voltage - IEC | 690V |
| Disconnect Type | - |
| Number of Levels | 1 |
| Stripping Length | 14mm |
| Terminal - Width | 10.2mm |
| Termination Style | Screw |
| Number of Positions | 2 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 6-20 AWG |
| Wire Gauge or Range - mm² | 0.5-16mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 114 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.74 | $2.69 | $2.63 |
Request Quote
