Image is for reference only , See Product Specifications
OA109AP-22-1WB
| Manufacturers: | Orion Fans |
|---|---|
| Product Category: | AC Fans |
| Data Sheet: | OA109AP-22-1WB |
| Description: | FAN AXIAL 120X38MM 230VAC WIRE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Orion Fans |
| Product Category | AC Fans |
| RPM | 3000 RPM |
| Noise | 37.0 dB |
| Width | 38.00mm |
| Series | OA109 |
| Weight | - |
| Air Flow | 110.0 CFM (3.08m³/min) |
| Fan Type | Tubeaxial |
| Features | - |
| Approvals | cURus, TUV |
| Part Status | Active |
| Termination | 2 Wire Leads |
| Bearing Type | Ball |
| Power (Watts) | 15.00W |
| Voltage Range | 160 ~ 260VAC |
| Static Pressure | 0.280 in H2O (69.7 Pa) |
| Voltage - Rated | 230VAC |
| Lifetime @ Temp. | 60000 Hrs @ 40°C |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Aluminum |
| Size / Dimension | Square - 119.5mm L x 119.5mm H |
| Ingress Protection | - |
| Current Rating (Amps) | - |
| Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) |
In Stock 599 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $17.19 | $16.85 | $16.51 |
