Image is for reference only , See Product Specifications
OA80AP-11-3TB
| Manufacturers: | Orion Fans |
|---|---|
| Product Category: | AC Fans |
| Data Sheet: | OA80AP-11-3TB |
| Description: | FAN AXIAL 80X38MM 115VAC TERM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Orion Fans |
| Product Category | AC Fans |
| RPM | 1950 RPM |
| Noise | 28.0 dB |
| Width | 38.00mm |
| Series | OA80 |
| Weight | - |
| Air Flow | 17.0 CFM (0.476m³/min) |
| Fan Type | Tubeaxial |
| Features | - |
| Approvals | cURus, TUV |
| Part Status | Active |
| Termination | 2 Terminals |
| Bearing Type | Ball |
| Power (Watts) | 9.00W |
| Voltage Range | 103 ~ 126VAC |
| Static Pressure | 0.070 in H2O (17.4 Pa) |
| Voltage - Rated | 115VAC |
| Lifetime @ Temp. | 60000 Hrs @ 40°C |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Aluminum |
| Size / Dimension | Square - 80mm L x 80mm H |
| Ingress Protection | - |
| Current Rating (Amps) | 0.100A |
| Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) |
In Stock 493 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.08 | $15.76 | $15.44 |
