Image is for reference only , See Product Specifications
EDZ500/2DS
| Manufacturers: | On-Shore Technology, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | EDZ500/2DS |
| Description: | TERM BLK 2P SIDE ENT 5.08MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | On-Shore Technology, Inc. |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Blue |
| Pitch | 0.200" (5.08mm) |
| Series | EDZ500/DS |
| Current | 15A |
| Voltage | 300V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 14-22 AWG |
| Part Status | Active |
| Screw Thread | M2.6 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.4 Nm (3.5 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Leaf Spring, Wire Guard |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 2 |
| Operating Temperature | -30°C ~ 105°C |
| Clamp Material - Plating | Steel, Stainless |
| Screw Material - Plating | - |
| Contact Material - Plating | Brass |
In Stock 2579 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.06 | $1.04 | $1.02 |
