Image is for reference only , See Product Specifications
0395430202
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0395430202 |
| Description: | TERM BLOCK 2POS 45DEG 5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.197" (5.00mm) |
| Series | Eurostyle ESE 39543 |
| Current | 10A |
| Voltage | 300V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 14-24 AWG |
| Part Status | Active |
| Screw Thread | - |
| Mounting Type | Through Hole |
| Torque - Screw | 0.34 Nm (3.0 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Leaf Spring, Wire Guard |
| Mating Orientation | 45° (135°) Angle with Board |
| Dielectric Material | Polyamide (PA66), Nylon 6/6 |
| Positions Per Level | 2 |
| Operating Temperature | -40°C ~ 105°C |
| Clamp Material - Plating | - |
| Screw Material - Plating | Steel |
| Contact Material - Plating | Brass - Tin Plated |
In Stock 3856 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.05 | $1.03 | $1.01 |
