Image is for reference only , See Product Specifications
178-015-413R491
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 178-015-413R491 |
| Description: | CONN D-SUB PLUG/RCPT 15POS R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 178 |
| Features | Board Lock, Grounding Indents, Shielded |
| Packaging | Tray |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | Stamped |
| Contact Type | Signal |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Connector Type | Plug, Male Pins; Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) |
| Number of Rows | 2, 2 |
| Voltage Rating | - |
| Backset Spacing | 0.318" (8.08mm) |
| Connector Style | D-Sub - Stacked |
| Contact Material | Brass |
| Ingress Protection | - |
| Dielectric Material | Polyamide (PA9T), Nylon 9T |
| Number of Positions | 15, 15 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 2 (DA, A); 2 (DA, A) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.09 | $6.95 | $6.81 |
