Image is for reference only , See Product Specifications
172-025-283L031
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 172-025-283L031 |
| Description: | CONN D-SUB RCPT 25P PNL MNT SLDR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 172, M Series |
| Features | - |
| Packaging | Tray |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | Machined |
| Contact Type | Signal |
| Mounting Type | Panel Mount, Through Hole |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Mating Side (4-40) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Sub |
| Contact Material | Brass |
| Ingress Protection | - |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Number of Positions | 25 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -50°C ~ 125°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 3 (DB, B) |
In Stock 37 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $17.87 | $17.51 | $17.16 |
