684S5W5103L461
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 684S5W5103L461 |
| Description: | CONN D-SUB PLUG 5POS R/A SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | Seal-D 684S |
| Features | Board Lock, Grounding Indents, Mounting Brackets |
| Packaging | Tray |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | Machined |
| Contact Type | Power |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) |
| Number of Rows | 1 |
| Voltage Rating | - |
| Backset Spacing | 0.520" (13.20mm) |
| Connector Style | D-Sub, Combo |
| Contact Material | Copper Alloy |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Number of Positions | 5 (Power) |
| Current Rating (Amps) | 40A |
| Operating Temperature | -55°C ~ 155°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 3 (DB, B) - 5W5 |
In Stock 41 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $17.20 | $16.86 | $16.52 |
