Image is for reference only , See Product Specifications
0528083070
| Manufacturers: | Molex |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 0528083070 |
| Description: | CONN FPC VERT 30POS 1.00MM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.039" (1.00mm) |
| Series | Easy-On 52808 |
| Features | - |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Termination | Solder |
| Housing Color | - |
| Mating Cycles | 10 |
| Mounting Type | Surface Mount |
| Actuator Color | - |
| Cable End Type | Straight |
| Contact Finish | Tin Bismuth |
| Flat Flex Type | FPC |
| Voltage Rating | 125V |
| Locking Feature | - |
| Contact Material | Phosphor Bronze |
| Actuator Material | - |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.199" (5.05mm) |
| Dielectric Material | Polyphenylene Sulfide (PPS) |
| Number of Positions | 30 |
| Current Rating (Amps) | 0.5A |
| Operating Temperature | -20°C ~ 85°C |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Contact Finish Thickness | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 6092 pcs
