Image is for reference only , See Product Specifications
0522071333
| Manufacturers: | Molex |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 0522071333 |
| Description: | CONN FFC FPC TOP 13POS 1MM R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.039" (1.00mm) |
| Series | Easy-On 52207 |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Termination | Solder |
| Housing Color | White |
| Mating Cycles | 30 |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Color | Brown |
| Cable End Type | Tapered |
| Contact Finish | Tin Bismuth |
| Flat Flex Type | FFC, FPC |
| Voltage Rating | 125V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.106" (2.70mm) |
| Dielectric Material | Polyamide (PA), Nylon, Glass Filled |
| Number of Positions | 13 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -40°C ~ 85°C |
| Connector/Contact Type | Contacts, Top |
| Contact Finish Thickness | 39.4µin (1.00µm) |
| Material Flammability Rating | UL94 V-0 |
In Stock 4534 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
