Image is for reference only , See Product Specifications
0399500110
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0399500110 |
| Description: | TERM BLK 10P SIDE ENTRY 8MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.315" (8.00mm) |
| Series | Eurostyle 39950 |
| Current | 20A |
| Voltage | 600V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 12-22 AWG |
| Part Status | Active |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.56 Nm (5.0 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Positions Per Level | 10 |
| Operating Temperature | -40°C ~ 130°C |
| Clamp Material - Plating | Brass - Nickel Plated |
| Screw Material - Plating | Steel - Zinc Chromate |
| Contact Material - Plating | Brass - Tin Plated |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $11.80 | $11.56 | $11.33 |
