Image is for reference only , See Product Specifications
0399200506
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0399200506 |
| Description: | TERM BLK 6P SIDE ENTRY 15MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.591" (15.00mm) |
| Series | Eurostyle 39920 |
| Current | 85A |
| Voltage | 600V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 3-14 AWG |
| Part Status | Active |
| Screw Thread | M5 |
| Mounting Type | Through Hole |
| Torque - Screw | 2.71 Nm (24 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Thermoplastic |
| Positions Per Level | 6 |
| Operating Temperature | -40°C ~ 130°C |
| Clamp Material - Plating | Brass - Nickel Plated |
| Screw Material - Plating | Steel, Stainless - Tin Plated |
| Contact Material - Plating | Copper - Tin Plated |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $11.69 | $11.46 | $11.23 |
