Image is for reference only , See Product Specifications
0387203203
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Barrier Blocks |
| Data Sheet: | 0387203203 |
| Description: | CONN BARRIER STRIP 3CIRC 0.375" |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Barrier Blocks |
| Color | Black |
| Pitch | 0.375" (9.53mm) |
| Series | Beau 38720 |
| Features | Flange |
| Packaging | Bulk |
| Wire Gauge | 14-22 AWG |
| Part Status | Active |
| Barrier Type | 2 Wall (Dual) |
| Mounting Type | Chassis, Panel |
| Number of Rows | 1 |
| Voltage Rating | 300V |
| Top Termination | Screws |
| Bottom Termination | Solder Turret, Insulated |
| Number of Circuits | 3 |
| Terminal Block Type | Barrier Block |
| Current Rating (Amps) | 15A |
| Material - Insulation | Thermoplastic |
| Operating Temperature | -40°C ~ 100°C |
| Terminal Screw Finish | Zinc, Clear Chromate |
| Number of Wire Entries | 3 |
| Terminal Screw Material | Steel |
| Material Flammability Rating | - |
In Stock 1067 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.96 | $2.90 | $2.84 |
