Image is for reference only , See Product Specifications
0508.500MXEP
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | Fuses |
| Data Sheet: | 0508.500MXEP |
| Description: | FUSE CERM 500MA 1000VAC/VDC 3AB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | Fuses |
| Color | - |
| Series | 508 |
| Approvals | CE, cULus |
| Fuse Type | Cartridge, Ceramic |
| Packaging | Bulk |
| Part Status | Active |
| Melting I²t | 0.259 |
| Mounting Type | Through Hole |
| Response Time | Fast Blow |
| Package / Case | 3AB, 3AG, 1/4" x 1-1/4" (Axial) |
| Size / Dimension | 0.275" Dia x 1.288" L (6.99mm x 32.72mm) |
| DC Cold Resistance | 3.572 Ohms |
| Voltage Rating - AC | 1kV |
| Voltage Rating - DC | 1000V |
| Current Rating (Amps) | 500mA |
| Operating Temperature | -55°C ~ 125°C |
| Breaking Capacity @ Rated Voltage | 10kA |
In Stock 1087 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $8.27 | $8.10 | $7.94 |
