UP2B-680-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | UP2B-680-R |
| Description: | FIXED IND 68UH 1.5A 178.7 MOHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | UNI-PAC™ |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Inductance | 68µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.550" L x 0.410" W (13.97mm x 10.41mm) |
| DC Resistance (DCR) | 178.7mOhm Max |
| Current - Saturation | 1.2A |
| Current Rating (Amps) | 1.5A |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
