Image is for reference only , See Product Specifications
1812R-824J
| Manufacturers: | API Delevan Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 1812R-824J |
| Description: | FIXED IND 820UH 67MA 45 OHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | API Delevan Inc. |
| Product Category | Fixed Inductors |
| Type | - |
| Series | 1812R |
| Ratings | - |
| Q @ Freq | 30 @ 790kHz |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±5% |
| Inductance | 820µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 1812 (4532 Metric) |
| Material - Core | Ferrite |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
| DC Resistance (DCR) | 45Ohm Max |
| Current - Saturation | - |
| Current Rating (Amps) | 67mA |
| Height - Seated (Max) | 0.134" (3.40mm) |
| Operating Temperature | -55°C ~ 125°C |
| Supplier Device Package | 1812 |
| Frequency - Self Resonant | 2.5MHz |
| Inductance Frequency - Test | 790kHz |
In Stock 5648 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
