Image is for reference only , See Product Specifications
A12503RNMCQ
| Manufacturers: | C&K |
|---|---|
| Product Category: | Rotary Switches |
| Data Sheet: | A12503RNMCQ |
| Description: | SWITCH ROTARY 8POS 2.5A 125V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | C&K |
| Product Category | Rotary Switches |
| Series | A |
| Features | Modular Base |
| Index Stops | Fixed |
| Part Status | Active |
| Actuator Type | Flatted (6.35mm Dia) |
| Mounting Type | Panel Mount, Through Hole |
| Angle of Throw | 45° |
| Contact Finish | Silver |
| Contact Timing | Non-Shorting (BBM) |
| Actuator Length | 9.53mm |
| Number of Decks | 1 |
| Operating Force | - |
| Circuit per Deck | SP8T |
| Contact Material | Silver (Ag) |
| Termination Style | PC Pin |
| Depth Behind Panel | 14.48mm |
| Number of Positions | 8 |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 125V |
| Current Rating (Amps) | 2.5A (AC), 350mA (DC) |
| Panel Cutout Dimensions | Circular - 9.80mm Dia |
| Number of Poles per Deck | 1 |
In Stock 40 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.41 | $7.26 | $7.12 |
