Image is for reference only , See Product Specifications
RM102002BCB
| Manufacturers: | C&K |
|---|---|
| Product Category: | Rotary Switches |
| Data Sheet: | RM102002BCB |
| Description: | SWITCH ROTARY 2POS 500MA 24V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | C&K |
| Product Category | Rotary Switches |
| Series | RM |
| Features | - |
| Index Stops | Fixed |
| Part Status | Active |
| Actuator Type | Screwdriver Slot |
| Mounting Type | Through Hole |
| Angle of Throw | 45° |
| Contact Finish | Gold |
| Contact Timing | Non-Shorting (BBM) |
| Actuator Length | Flush |
| Number of Decks | 1 |
| Operating Force | 2.700gfm |
| Circuit per Deck | SPDT |
| Contact Material | Brass |
| Termination Style | PC Pin |
| Depth Behind Panel | 7.37mm |
| Number of Positions | 2 |
| Voltage Rating - DC | 24V |
| Current Rating (Amps) | 500mA (DC) |
| Panel Cutout Dimensions | - |
| Number of Poles per Deck | 1 |
In Stock 135 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.27 | $2.22 | $2.18 |
Request Quote
