Image is for reference only , See Product Specifications
SSQ 8
| Manufacturers: | Bel Fuse, Inc. |
|---|---|
| Product Category: | Fuses |
| Data Sheet: | SSQ 8 |
| Description: | FUSE BRD MNT 8A 125VAC 86VDC SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bel Fuse, Inc. |
| Product Category | Fuses |
| Color | - |
| Series | SSQ |
| Approvals | CE, cULus |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Packaging | Digi-Reel® |
| Part Status | Not For New Designs |
| Melting I²t | 26 |
| Mounting Type | Surface Mount |
| Response Time | Fast Blow |
| Package / Case | 2-SMD, Square End Block |
| Size / Dimension | 0.240" L x 0.100" W x 0.100" H (6.10mm x 2.54mm x 2.54mm) |
| DC Cold Resistance | 0.008 Ohms |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 86V |
| Current Rating (Amps) | 8A |
| Operating Temperature | -55°C ~ 125°C |
| Breaking Capacity @ Rated Voltage | 50A AC, 10kA DC |
In Stock 46538 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
