Image is for reference only , See Product Specifications
0259.250T
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | Electrical, Specialty Fuses |
| Data Sheet: | 0259.250T |
| Description: | FUSE BRD MNT 250MA 125VAC/VDC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | Electrical, Specialty Fuses |
| Class | - |
| Series | 259 |
| Features | Intrinsically Safe |
| Approvals | Baseefa, UR |
| Fuse Type | Board Mount |
| Packaging | Bulk |
| Part Status | Active |
| Applications | Hazardous Locations |
| Melting I²t | 0.0095 |
| Mounting Type | Through Hole |
| Response Time | Fast Blow |
| Package / Case | Radial, Can, Horizontal |
| Size / Dimension | 0.315" Dia x 0.512" L (8.00mm x 13.00mm) |
| DC Cold Resistance | 0.67 Ohms |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 125V |
| Current Rating (Amps) | 250mA |
| Operating Temperature | -55°C ~ 90°C |
| Breaking Capacity @ Rated Voltage | 50A AC, 300A DC |
In Stock 708 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.10 | $5.98 | $5.86 |
