Image is for reference only , See Product Specifications
JCG1224S12
| Manufacturers: | XP Power |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | JCG1224S12 |
| Description: | DC DC CONVERTER 12V 12W |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | XP Power |
| Product Category | DC DC Converters |
| Type | Isolated Module |
| Series | JCG (12W) |
| Features | Remote On/Off, OCP, OVP, SCP, UVLO |
| Packaging | Tube |
| Efficiency | 90% |
| Part Status | Active |
| Applications | ITE (Commercial) |
| Mounting Type | Through Hole |
| Power (Watts) | 12W |
| Package / Case | 24-DIP Module, 8 Leads |
| Control Features | Enable, Active High |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Isolation | 1.6kV |
| Operating Temperature | -40°C ~ 100°C |
| Voltage - Input (Max) | 36V |
| Voltage - Input (Min) | 18V |
| Current - Output (Max) | 1A |
In Stock 77 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $30.00 | $29.40 | $28.81 |
