Image is for reference only , See Product Specifications
860241181007
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | 860241181007 |
| Description: | CAP 150 UF 20% 250 V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | WCAP-AT1H |
| Ratings | - |
| Packaging | Cut Tape (CT) |
| Tolerance | ±20% |
| Capacitance | 150µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 0.295" (7.50mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Voltage - Rated | 250V |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 1.319" (33.50mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 935mA @ 120Hz |
| Ripple Current @ High Frequency | 1.87A @ 100kHz |
| ESR (Equivalent Series Resistance) | - |
In Stock 172 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.64 | $4.55 | $4.46 |
