Image is for reference only , See Product Specifications
7499211002A
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Modular Connectors - Jacks With Magnetics |
| Data Sheet: | 7499211002A |
| Description: | CONN MAGJACK 1PORT 100 BASE-T |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Modular Connectors - Jacks With Magnetics |
| Series | WE-RJ45 LAN |
| Features | Board Guide |
| LED Color | Does Not Contain LED |
| Packaging | Tube |
| Shielding | Shielded, EMI Finger |
| Orientation | 90° Angle (Right) |
| Part Status | Active |
| Termination | Solder |
| Applications | 10/100 Base-T, AutoMDIX, Power over Ethernet (PoE) |
| Mounting Type | Through Hole |
| Tab Direction | Down |
| Connector Type | RJ45 |
| Contact Finish | Gold |
| Number of Rows | 1 |
| Number of Ports | 1 |
| Shield Material | Copper Alloy |
| Contact Material | Tin |
| Height Above Board | 0.541" (13.75mm) |
| Dielectric Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Number of Cores per Jack | 4 |
In Stock 19 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $9.41 | $9.22 | $9.04 |
Request Quote
