Image is for reference only , See Product Specifications
7447790470
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 7447790470 |
| Description: | FIXED IND 47UH 1.45A 160 MOHM TH |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | WE-TI |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Tray |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 47µH |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Material - Core | Ferrite |
| Size / Dimension | 0.307" Dia (7.80mm) |
| DC Resistance (DCR) | 160mOhm Max |
| Current - Saturation | 1.1A |
| Current Rating (Amps) | 1.45A |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 10.2MHz |
| Inductance Frequency - Test | 1kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.13 | $1.11 | $1.09 |
