7447785147
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 7447785147 |
| Description: | FIXED IND 47UH 850MA 600 MOHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | WE-PD Robust |
| Ratings | AEC-Q200 |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Tolerance | ±25% |
| Inductance | 47µH |
| Part Status | Discontinued at Digi-Key |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.244" L x 0.232" W (6.20mm x 5.90mm) |
| DC Resistance (DCR) | 600mOhm Max |
| Current - Saturation | 740mA |
| Current Rating (Amps) | 850mA |
| Height - Seated (Max) | 0.130" (3.30mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 16.5MHz |
| Inductance Frequency - Test | 100kHz |
