Image is for reference only , See Product Specifications
7447714680
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 7447714680 |
| Description: | FIXED IND 68UH 1.9A 132 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | WE-PD Performance |
| Ratings | AEC-Q200 |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 68µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.394" L x 0.394" W (10.00mm x 10.00mm) |
| DC Resistance (DCR) | 132mOhm Max |
| Current - Saturation | 2.2A |
| Current Rating (Amps) | 1.9A |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 8MHz |
| Inductance Frequency - Test | 100kHz |
In Stock 1458 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
