Image is for reference only , See Product Specifications
744770182
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 744770182 |
| Description: | FIXED IND 82UH 2.25A 160 MOHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | WE-PD |
| Ratings | AEC-Q200 |
| Q @ Freq | - |
| Packaging | Tape & Reel (TR) |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 82µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| DC Resistance (DCR) | 160mOhm Max |
| Current - Saturation | 2.45A |
| Current Rating (Amps) | 2.25A |
| Height - Seated (Max) | 0.315" (8.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 3.5MHz |
| Inductance Frequency - Test | 1kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.39 | $1.36 | $1.33 |
