Image is for reference only , See Product Specifications
744758327A
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 744758327A |
| Description: | FIXED IND 2.7UH 520MA 1.1 OHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | WE-RFH |
| Ratings | - |
| Q @ Freq | 20 @ 7.96MHz |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±5% |
| Inductance | 2.7µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 1008 (2520 Metric) |
| Material - Core | Ferrite |
| Size / Dimension | 0.102" L x 0.083" W (2.60mm x 2.10mm) |
| DC Resistance (DCR) | 1.1Ohm Max |
| Current - Saturation | - |
| Current Rating (Amps) | 520mA |
| Height - Seated (Max) | 0.075" (1.90mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 1008 (2520 Metric) |
| Frequency - Self Resonant | 135MHz |
| Inductance Frequency - Test | 7.96MHz |
In Stock 4587 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
