Image is for reference only , See Product Specifications
691137710002
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 691137710002 |
| Description: | TERM BLK 2POS SIDE ENTRY 5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | 0.197" (5.00mm) |
| Series | WR-TBL Series 1377 |
| Current | 16A |
| Voltage | 300V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 12-30 AWG |
| Part Status | Active |
| Screw Thread | M2.5 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.4 Nm (3.5 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Leaf Spring, Wire Guard |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polycarbonate (PC) |
| Positions Per Level | 2 |
| Operating Temperature | -30°C ~ 120°C |
| Clamp Material - Plating | Copper Alloy |
| Screw Material - Plating | Zinc Plated |
| Contact Material - Plating | Copper Alloy - Nickel Plated |
In Stock 1657 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.38 | $0.37 | $0.36 |
