Image is for reference only , See Product Specifications
686118183522
| Manufacturers: | Wurth Electronics Inc. |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 686118183522 |
| Description: | CONN FFC BTM 18POS 1MM SMD R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Wurth Electronics Inc. |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.039" (1.00mm) |
| Series | WR-FPC |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Packaging | Digi-Reel® |
| Part Status | Discontinued at Digi-Key |
| Termination | Solder |
| Housing Color | Ivory |
| Mating Cycles | 20 |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Color | Black |
| Cable End Type | Straight |
| Contact Finish | Tin |
| Flat Flex Type | FFC |
| Voltage Rating | - |
| Locking Feature | Flip Lock |
| Contact Material | Phosphor Bronze |
| Actuator Material | Polyamide (PA6T), Nylon 6T |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.047" (1.20mm) |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Number of Positions | 18 |
| Current Rating (Amps) | 0.8A |
| Operating Temperature | -25°C ~ 85°C |
| Connector/Contact Type | Contacts, Bottom |
| Contact Finish Thickness | 120.0µin (3.05µm) |
| Material Flammability Rating | UL94 V-0 |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
