Image is for reference only , See Product Specifications
1825800000
| Manufacturers: | Weidmuller |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1825800000 |
| Description: | TERM BLK 3POS TOP ENT 3.81MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Weidmuller |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.150" (3.81mm) |
| Series | Omnimate LSF-SMT |
| Current | 12A |
| Voltage | 300V |
| Features | - |
| Packaging | Tube |
| Wire Gauge | 16-24 AWG |
| Part Status | Active |
| Screw Thread | - |
| Mounting Type | Through Hole |
| Torque - Screw | - |
| Number of Levels | 1 |
| Wire Termination | Screwless - Push Button Clamp |
| Mating Orientation | Vertical with Board |
| Dielectric Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Positions Per Level | 3 |
| Operating Temperature | -50°C ~ 240°C |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | Copper Alloy - Tin Plated |
In Stock 300 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.85 | $1.81 | $1.78 |
