Image is for reference only , See Product Specifications
1724680000
| Manufacturers: | Weidmuller |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1724680000 |
| Description: | TERM BLK 2P SIDE ENT 9.53MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Weidmuller |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Orange |
| Pitch | 0.375" (9.53mm) |
| Series | LL |
| Current | 30A |
| Voltage | 300V |
| Features | Interlocking (Side) |
| Packaging | Bulk |
| Wire Gauge | 10-26 AWG |
| Part Status | Active |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Clamping Yoke, Tension Sleeve |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Thermoplastic, Wemid |
| Positions Per Level | 2 |
| Operating Temperature | -50°C ~ 120°C |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | Copper Alloy - Tin Plated |
In Stock 300 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.38 | $2.33 | $2.29 |
