1289530000
| Manufacturers: | Weidmuller |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1289530000 |
| Description: | TERM BLOCK HDR 20POS 90DEG 3.5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Weidmuller |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Color | Black |
| Pitch | 0.138" (3.50mm) |
| Series | Omnimate S2C |
| Features | Mating Flange, Solder Retention |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 10A |
| Voltage - UL | 150V |
| Current - IEC | 13.4A |
| Mounting Type | Through Hole |
| Voltage - IEC | 200V |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Copper Alloy |
| Number of Levels | 2 |
| Insulation Height | 0.425" (10.80mm) |
| Termination Style | Solder |
| Wire Strip Length | - |
| Header Orientation | 90°, Right Angle |
| Ingress Protection | IP20 |
| Contact Tail Length | 0.126" (3.20mm) |
| Dielectric Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Number of Positions | 20 |
| Positions Per Level | 10 |
| Contact Mating Finish | Tin |
| Operating Temperature | -50°C ~ 120°C |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $10.07 | $9.87 | $9.67 |
