Image is for reference only , See Product Specifications
1186780000
| Manufacturers: | Weidmuller |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 1186780000 |
| Description: | CONN TERM BLK FEED THRU 6-18 AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Weidmuller |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Blue |
| Series | W |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 49A |
| Voltage - UL | 600V |
| Current - IEC | 57A |
| Voltage - IEC | 800V |
| Disconnect Type | - |
| Number of Levels | 2; Connected |
| Stripping Length | 12mm |
| Terminal - Width | 9.9mm |
| Termination Style | Screw |
| Number of Positions | 4 |
| Material - Insulation | Thermoplastic, Wemid |
| Wire Gauge or Range - AWG | 6-18 AWG |
| Wire Gauge or Range - mm² | 1.5-16mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 46 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $14.56 | $14.27 | $13.98 |
