Image is for reference only , See Product Specifications
1013690000
| Manufacturers: | Weidmuller |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1013690000 |
| Description: | TERM BLOCK PLUG 3POS STR 5.08MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Weidmuller |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Orange |
| Pitch | 0.200" (5.08mm) |
| Series | Omnimate BL |
| Features | Retention Latches (Non-Wire Side) |
| Packaging | Box |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 18.5A |
| Voltage - UL | 300V |
| Current - IEC | 24A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 400V |
| Torque - Screw | - |
| Plug Wire Entry | 180° |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.559" (14.20mm) |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Wire Strip Length | 10mm |
| Header Orientation | - |
| Ingress Protection | IP20 |
| Contact Tail Length | - |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Number of Positions | 3 |
| Positions Per Level | 3 |
| Contact Mating Finish | Tin |
| Operating Temperature | -50°C ~ 100°C |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm² | 0.2-2.5mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 230 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.53 | $3.46 | $3.39 |
