Image is for reference only , See Product Specifications
VOT8025AD-V
| Manufacturers: | Vishay / Semiconductor - Opto Division |
|---|---|
| Product Category: | Optoisolators - Triac, SCR Output |
| Data Sheet: | VOT8025AD-V |
| Description: | OPTOCOUPLER PHOTOTRIAC 800V DIP5 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Vishay / Semiconductor - Opto Division |
| Product Category | Optoisolators - Triac, SCR Output |
| Series | - |
| Approvals | CQC, cUL, UL, VDE |
| Packaging | Tube |
| Output Type | Triac |
| Part Status | Active |
| Turn On Time | - |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP (0.300", 7.62mm), 5 Leads |
| Number of Channels | 1 |
| Static dV/dt (Min) | 1kV/µs |
| Current - Hold (Ih) | 400µA (Typ) |
| Voltage - Isolation | 5300Vrms |
| Voltage - Off State | 800V |
| Operating Temperature | -40°C ~ 110°C |
| Zero Crossing Circuit | Yes |
| Supplier Device Package | 6-DIP |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50mA |
| Current - LED Trigger (Ift) (Max) | 5mA |
| Current - On State (It (RMS)) (Max) | 100mA |
In Stock 100 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.12 | $1.10 | $1.08 |
