Image is for reference only , See Product Specifications
IMC1812ER221K
| Manufacturers: | Vishay / Dale |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | IMC1812ER221K |
| Description: | FIXED IND 220UH 100MA 10 OHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Vishay / Dale |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | IMC-1812 |
| Ratings | - |
| Q @ Freq | 40 @ 790kHz |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 220µH |
| Part Status | Discontinued at Digi-Key |
| Mounting Type | Surface Mount |
| Package / Case | 1812 (4532 Metric) |
| Material - Core | Ferrite |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
| DC Resistance (DCR) | 10Ohm Max |
| Current - Saturation | - |
| Current Rating (Amps) | 100mA |
| Height - Seated (Max) | 0.134" (3.40mm) |
| Operating Temperature | -55°C ~ 125°C |
| Supplier Device Package | 1812 |
| Frequency - Self Resonant | 4MHz |
| Inductance Frequency - Test | 790kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
