PTCCL07H321DTE
| Manufacturers: | Vishay BC Components |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | PTCCL07H321DTE |
| Description: | PTC RESET FUSE 30V 320MA RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Vishay BC Components |
| Product Category | PTC Resettable Fuses |
| Type | Ceramic |
| Series | PTCCL |
| Ratings | - |
| Approvals | UR |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Lead Spacing | 0.197" (5.00mm) |
| Current - Max | 3.5A |
| Mounting Type | Through Hole |
| Voltage - Max | 30V |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | 0.276" Dia x 0.157" T (7.00mm x 4.00mm) |
| Current - Trip (It) | 480mA |
| Height - Seated (Max) | 0.472" (12.00mm) |
| Operating Temperature | -40°C ~ 85°C |
| Resistance - 25°C (Typ) | 5 Ohms |
| Current - Hold (Ih) (Max) | 320mA |
